MER3-514-235X2M

₹45,900

• C Mount	• 2448×2048
• CUSTOMIZED	• 2/3 INCH
• 235 FPS	• CMOS
• GLOBAL SHUTTER	• MONO

Standard Delivery: 2-3 weeks

🗸 Standard delivery: 2-3 weeks 🗸 In-stock: Same day shipping

🗸 3 years warranty 🗸 Certified by TÜV Rheinland

Description

DESCRIPTION

CoaXPress Vision Camera Customized Sensor

The MER3-514-235X2M is a high-performance 5-megapixel CoaXPress industrial camera engineered for advanced machine vision applications. It delivers exceptional image quality and high-speed data transmission, making it well suited for demanding industrial inspection, scientific research, and medical imaging tasks.

Leveraging the CoaXPress interface, the camera provides very high-resolution imaging at elevated frame rates while ensuring a stable, high-bandwidth connection between the camera and the frame grabber.
To fully optimize the capabilities of the customized sensor, the camera is equipped with a C-mount interface. You can find our recommended lenses here.

This CoaXPress model is ideal for applications that meet the following criteria:

Require an industrial CoaXPress camera
C-mount

Camera dimensions: 74 × 74 × 60 mm

Industrial Monochrome Camera

A monochrome, or black-and-white, camera is designed to capture images without color information, making it highly effective in industrial and scientific applications. Unlike color cameras, which divide incoming light into multiple channels, monochrome cameras use the full sensor for brightness detection. This results in greater light sensitivity, sharper images, and reduced data volume, which significantly improves the speed and efficiency of image processing.

By pairing monochrome cameras with the right lighting wavelengths and lens filters, specific product characteristics can be emphasized, creating high-contrast, high-resolution images. This makes them ideal for tasks such as inspection, measurement, and machine vision, where precision and detail are critical. Their ability to deliver consistent performance in controlled environments has established monochrome cameras as a reliable choice for industrial imaging.

MTBF, Warranty & Product Life Cycle

Daheng Imaging produce yearly more than 1,00,000 industrial cameras according to the highest quality standards. The mean time between failure (MTBF) is more than 400.000 hours (45 years, 24/7). The industrial cameras are certified by TÜV Rheinland and have a 3 year warranty. After market introduction, every camera model is at least available for 7 years. Most cameras have even a much longer product life cycle.

Datasheet | User manual | Software & SDK | 3D Step

SPECIFICATIONS

Part number	MER3-514-235X2M
Interface	CXP Vision
Resolution	2448×2048
Frame rate	235 fps
Pixel size	3.4 μm
Color/Mono	Mono
Sensor type	Customized
Sensor size	2/3″
Shutter Type	Global Shutter
Shutter time	6μs ~ 1s
ADC Bit Depth	10bit, 12bit
Pixel bit depth	8bit, 10bit , 12bit
Digital Gain	0db ~ 16db
Pixel data format	Mono8 / Mono10 / Mono12
Synchronization	HW & SW Trigger
I/O	1 Input + 1 Output + 2 GPIO
Operating temp.	0°C ~ 45°C
Humidity	10% ~ 80%
Mount	C
Dimensions	29x29x33.1mm
SDK	DAHENG IMAGING or third-party frame grabbers supporting software
Power	3.6 W @ PoCXP
Weight	520g
Compliance	CE, RoHS, FCC, ICES, UKCA, CoaXPress2.0, GenICam
Megapixel	60 MP
Old Part #	MER3-514-235X2M
